Q690 Channel Hlau Khoom Piav
Q690 Hlau thiab Q690M Cov Khoom Sivyog Suav GB tus qauv siab qes qis alloy txheej txheem hlau, thiab teeb meem rau hauv 3 qib khoom tau zoo:Q690C, Q690D thiab Q690e, "Q" txhais tau tias tau lees paub lub zog, "690" yog hais txog 690 MPa tswj tau "TMCP" (rau cov ntaub ntawv cov ntaub ntawv thiab cov ntaub ntawv tshwj xeeb, thov saib cov ntawv hauv qab no.
Cov phiaj hlau ua los ntawm Q690 channel steel muaj siab tawm lub zog thiab tensile lub zog thiab siv tau hydraulic, chaw nres nkoj cranes, flatbed truck thiab lwm yam.
Q690 Hlau Tshuaj Muaj pes tsawg leeg
Cov tshuaj compositon ntawm Q690C, Q690D, Q690E tau tshwm sim hauv cov lus hauv qab no.
| Q690 Kev Siv Tshuaj Muaj Tshuaj (%) | ||||||||||||||||
| Qib hlau | Tau Qib Siab | C | Si | Mn | P | S | Nb | V | Ti | Cr | Ni | CU | N | Mo | B | Al |
| Q690 | Q690C | Tsawg dua los yog sib npaug rau 0.18 | Tsawg dua los yog sib npaug rau 0.60 | Tsawg dua los yog sib npaug rau 2.00 | Tsawg dua los yog sib npaug rau 0.030 | Tsawg dua los yog sib npaug rau 0.030 | Tsawg dua los yog sib npaug rau 0.11 | Tsawg dua los yog sib npaug rau 0.12 | Tsawg dua los yog sib npaug rau 0.20 | Tsawg dua los yog sib npaug rau 1.00 | Tsawg dua los yog sib npaug rau 0.80 | Tsawg dua los yog sib npaug rau 0.80 | Tsawg dua los yog sib npaug rau 0.015 | Tsawg dua los yog sib npaug rau 0.30 | Tsawg dua los yog sib npaug rau 0.004 | Ntau dua los yog sib npaug rau 0.015 |
| Q690D | Tsawg dua los yog sib npaug rau 0.030 | Tsawg dua los yog sib npaug rau 0.025 | ||||||||||||||
| Q690E | Tsawg dua los yog sib npaug rau 0.025 | Tsawg dua los yog sib npaug rau 0.020 | ||||||||||||||
Q690 cov nqi roj (CEV): tsawg dua lossis sib npaug rau 0.49% (suav nrog C, D, E; txhua lub cheeb)
Q690 Hlau Cov Khoom Siv Neeg Kho Tshuab
| Q690 Sawv Cev Zog(Ntau dua los yog sib npaug rau N / MM2); Tuab lossis dia. d (hli) | ||||||
| Lub hom phiaj | Qib hlau | Zoo heev | D Tsawg dua lossis sib npaug rau 16 | 16 | 40 | 63 |
| GB / T 1591 - 2008 | Q690 | C, D, E | 690 | 670 | 660 | 640 |
| GB / T 1591 - 2018 | Q690M | C, D, E | 690 | 680 | 670 | 650 |
| Q690 tensile lub zog(N / MM2); d (hli) | Elongation | |||||
| Lub hom phiaj | Qib hlau | Zoo heev | D Tsawg dua lossis sib luag rau 40 | 40 | 63 | % |
| GB / T 1591 - 2008 | Q690 | C, D, E | 770-940 | 750-920 | 730-900 | Ntau dua los yog sib npaug rau 14 |
| GB / T 1591 - 2018 | Q690M | C, D, E | 770-940 | 750-920 | 730-900 | Ntau dua los yog sib npaug rau 14 |
Q690 channel steel yog ntev bar ntawm steel nrog ib tug zawj seem. Nws yog cov pa roj teeb cov hlau nrog kev tsim kho thiab tshuab. Nws yog ib tshooj ntawm cov hlau nrog ntu nyuaj, thiab nws cov ntu yog ib qho zawj. Channel hlau feem ntau yog siv hauv kev tsim qauv qauv, kab hlau rhuav phab ntsa engineering, cov khoom siv kho tshuab thiab tsheb tsim khoom.
Ntim thiab Xa Khoom
Dej pov thawj ntawv pov thawj, thiab hlau sawb ntim. Txheem export seaworthy pob.suit rau txhua yam kev thauj, lossis raws li yuav tsum tau ua.
Cov ntim thiab tsheb thauj mus los1) 6M thauj los ntawm 20ft thawv, 12m thauj khoom los ntawm 40ft thawv
2) 12m twisted steel bar loaded los ntawm 20ft thawv
3) Cov ntau npaum li cas loaded los ntawm lub nkoj feem ntau
Ntim loj
20ft GP: 5.8M (L) * 2.35m (w) * 2.39m (h) 26Cb
40ft GP: 11.8M (L) * 2.35m (w) * 2.39m (h) 56cbm
40ft HQ: 11.8m (L) * 2.35M (w) * 2.69m (h) 65cbm
Qhov kev lag luam no
Gnee Steel Group yog cov khoom siv cov khoom lag luam ua ke nrog rau cov hlau phaj xws li cov khoom tsim qauv hlau, profile, sab nraum zoov tsim qauv thiab kev ua. Tsim tau nyob rau xyoo 2008, nrog 5 lab RMB sau npe peev, tam sim no cov nyiaj tau nce mus txog 30 lab RMB, cheeb tsam rhiav ntau dua 35000㎡, nrog rau 200 tus neeg ua haujlwm.
Cim npe nrov: Q690 Channel Hlau, Suav Teb Q690 Channel Hlau Cov Chaw Tsim Tshuaj, Chaw muag khoom, Hoobkas
