P460NH Boiler Cov Khoom Siv Khoom Zoo
P460NHHlab Phajyog ib tug nkag mus - ionistant weldable alloy high- qib steel. Cov kav dej ua los ntawm cov hlau no tau siv rau cov qauv hlab siab, cov qauv txheej txheem, cov qauv siv hluav taws xob thiab cov qauv siv khoom siv. Kev pabcuam kub: Txog 400 degrees Celsius.
Lub zog tensile ntawm P460NHBoiler PhajNrog ib tuab ntawm tsawg dua 60 hli yog 570 txog 720 MPa, thiab qhov siab tshaj plaws tensile lub zog ntawm cov phaj ntawm li 16 hli tuaj yeem ncav 730 MPa.
P460NH boiler phaj hlau cov hlau cov khoom
| C | Si | Mn | Ni | P | S | Cr | Mo | V | N | Nb | Ti | Al | CU | - |
| Max 0.2 | Max 0.5 | 1.1 - 1.7 | Max 0.8 | Max 0.025 | Max 0.015 | Max 0.3 | Max 0.1 | Max 0.2 | Max 0.025 | Max 0.05 | Max 0.03 | Max 0.02 | Max 0.7 | Nb + ti + v <0.22 |
P460NH Siab Ntsig Ntsig Rau Cov Khoom Siv Phaj
| Teem nqi | Qhov tuab | Pub | Tensilmie | Elongation | Kev Cuam Tshuam Lub Zog (KV j) min | ||
| P460NH | lub hli | Min MPa | MPa | Min% | -20 degree | 0 Qib | +20 degree |
| Tsawg dua los yog sib luag rau 16 | 460 | 570-720 | 17 | 47 | 55 | 63 | |
| 16>rau tsawg dua lossis sib npaug rau 35 | 450 | 570-720 | 17 | 47 | 55 | 63 | |
| 35>rau tsawg dua lossis sib npaug rau 50 | 440 | 570-720 | 17 | 47 | 55 | 63 | |
| 50>rau tsawg dua lossis sib npaug rau 70 | 420 | 570-720 | 17 | 47 | 55 | 63 | |
| 70>rau tsawg dua lossis sib npaug rau 100 | 400 | 540-710 | 16 | 47 | 55 | 63 | |
| 100>rau tsawg dua lossis sib npaug rau 150 | 380 | 520-690 | 16 | 47 | 55 | 63 | |
P460NH Lub Nkoj Hlau Hlau Thermal Khoom
| Ntiag tug | Qho so | Tus nqi |
|---|---|---|
|
Coefficient ntawm thermal expansion |
-100.0 Degree |
1.05E-5 1/K |
|
20.0 Degree |
1.15E-5 1/K |
|
|
100.0 DEGREE |
1.21E-5 1/K |
|
|
200.0 Degree |
1.27E-5 1/K |
|
|
300.0 Degree |
1.32E-5 1/K |
|
|
400.0 degree |
1.36E-5 1/K |
|
|
500.0 degree |
1.4E-5 1/K |
|
|
600.0 Degree |
1.44E-5 1/K |
|
|
MAX Kev Pab Cuam Tshuam Kub, Ntev |
0 - 400 degree |
|
|
Kev Kub Loj Tshaj |
-100.0 Degree |
423 J / (KGB · K) |
|
20.0 Degree |
461 J / (KGB · K) |
|
|
100.0 DEGREE |
479 j / (KGB · K) |
|
|
200.0 Degree |
499 J / (KGB · K) |
|
|
300.0 Degree |
517 J / (KGB · K) |
|
|
400.0 degree |
536 J / (KGB · K) |
|
|
500.0 degree |
558 J / (KGB · K) |
|
|
600.0 Degree |
587 j / (KGB · K) |
Kub Rolled Boiler Hlau Daim Hlau Khoom Duab
Gnee Pawg Pab Pawg Duab
Gnee Pab Pawg Neeg Siv Khoom Mus Xyuas
Gnee Group Exhibition
Peb cov khoom tau cuam tshuam nruj nruj ua tau zoo kev soj ntsuam thiab tau nruab nrog daim ntawv pov thawj rau kev ua haujlwm. Yog koj muaj lus nug txog P460NH Boiler Cov Khoom Siv Zoo, koj tau txais tos kom kuaj.
Cim npe nrov: P460NH Boiler Khoom Siv Khoom Siv Zoo, Tuam Tshoj P460NH Boiler Khoom Tsim Khoom, Chaw muag khoom, Hoobkas
