SM400 steel phaj

Dec 04, 2025 Tso lus

SM400A, SM400B thiab SM400C steel daim hlau yog Japanese txheem dov steel rau vuam qauv, S sawv cev rau hlau, M sawv cev rau vuam, 400 kuj yog qhov qis qis tensile zog 400MPa, A yog cov hlau phaj qib, tsis muaj kev cuam tshuam, B yog cov hlau phaj qib, cuam tshuam ntawm 20℃steel phaj, C qib siab.

Txuj ci rau SM400A, SM400B thiab SM400C steel daim hlau: JIS G3106.

Melting tsom xam ntawm cov tshuaj muaj pes tsawg leeg ntawm SM400A, SM400B thiab SM400C steel daim hlau:

Qib	Thickness	C	Si	Mn	P	S
Qauv: SM400A	t Tsawg dua lossis sib npaug li 50mm	Tsawg dua lossis sib npaug li 0.23	-	Ntau dua lossis sib npaug li 2.5	Tsawg dua lossis sib npaug li 0.035	Tsawg dua lossis sib npaug li 0.035
	50	Tsawg dua los yog sib npaug li 0.25
SM400B	t Tsawg dua lossis sib npaug li 50mm	Tsawg dua los yog sib npaug li 0.20	Tsawg dua lossis sib npaug li 0.35	0.60-1.50	Tsawg dua lossis sib npaug li 0.035	Tsawg dua lossis sib npaug li 0.035
	50	Tsawg dua lossis sib npaug li 0.22
SM 400 C	t Tsawg dua lossis sib npaug li 100mm	Tsawg dua lossis sib npaug li 0.18	Tsawg dua lossis sib npaug li 0.35	0.60-1.50	Tsawg dua lossis sib npaug li 0.035	Tsawg dua lossis sib npaug li 0.035

Mechanical zog ntawm SM400A, SM400B thiab SM400C steel daim hlau:

Qib	Tawm taw tes lossis tawm lub zog, N / m㎡						Lub zog tensile
	Thickness hli						Thickness hli
	Tsawg dua los yog sib npaug li 16	16	40	75	100	100	Tsawg dua los yog sib npaug li 100
Qauv: SM400A	Ntau dua lossis sib npaug li 245	Ntau dua lossis sib npaug li 235	Ntau dua lossis sib npaug li 215	Ntau dua lossis sib npaug li 215	Ntau dua lossis sib npaug li 205	Ntau dua lossis sib npaug rau 195	400-510
SM400B	Ntau dua lossis sib npaug li 245	Ntau dua lossis sib npaug li 235	Ntau dua lossis sib npaug li 215	Ntau dua lossis sib npaug li 215	Ntau dua lossis sib npaug li 205	-	400-510
SM 400 C	Ntau dua lossis sib npaug li 245	Ntau dua lossis sib npaug li 235	Ntau dua lossis sib npaug li 215	Ntau dua lossis sib npaug li 215	-	-	400-510
