Tus nqi -Kev Pabcuam ntawm S690Q kub dov steel phaj hauv Choj Qhov hnyav

Hauv kev tsim choj choj, cov khoom siv hnyav ncaj qha cuam tshuam rau kev tsim choj, kev tsim kho nyuaj, thiab lub neej - nqi mus ncig.S690Q kub dov steel phaj tau dhau los ua cov khoom siv tseem ceeb rau kev txo qhov hnyav vim nws qhov zoo ntawm qhov muaj zog tshwj xeeb (lub zog / ntom) - piv nrog cov tib yamcarbon steel phaj, nyob rau hauv tib lub load-cov kabmob muaj peev xwm,S690Q kub dov steel phajtuaj yeem ua tiav qhov hnyav txo qhov hnyav ntawm 30%, thiab txo qis tus nqi.

cas

Ntu txuas txuas ntawm tus hla- txoj haujlwm choj tus dej yog tsim los sivQ345B kub dov steel phaj(yield zog 345MPa), nrog lub web phaj thickness ntawm 32mm thiab flange phaj thickness ntawm 40mm; tom qab ntawd, nws tau hloov nrogS690Q kub dov steel phaj, lub vev xaib phaj tuab tau hloov kho mus rau 22 hli, thiab flange phaj thickness mus rau 28 hli, thaum ua kom seem khoov modulus tsis hloov. Qhov hnyav, tus nqi tsim kho, thiab kev ua haujlwm thiab kev saib xyuas tus nqi ntawm ob lub tswv yim tau muab piv.

Qhov hnyav txo qhov cuam tshuam thiab txo tus nqi ncaj qha

Khoom hnyav: Rau ib qho 12-meter-ntev choj lub thawv girder, qhov hnyav ntawm Q345B tswvyim yog 18.6 tonnes, thiab qhov hnyav ntawm qhovS690Q kub dov steel phajLub tswv yim yog 13.0 tonnes, nrog qhov hnyav txo ntawm 5.6 tonnes thiab qhov hnyav txo ntawm 30.1%. Muab xam los ntawm tus nqi ntawm cov khoom siv steel (Q345B yog li CNY 4,500 ib tonne, S690Q yog hais txog CNY 6,800 ib tonne), cov khoom siv tus nqi ntawm ib lub thawv girder yog: CNY 83,700 rau Q345B scheme thiab CNY 88,400 rau CNY 7 scheme nkaus xwb.

Kev Thauj Mus Los thiab Hoisting Tus Nqi: Tom qab txo qhov hnyav, lub tsheb thauj mus los rau ib lub thawv girder tau hloov los ntawm ib qho hnyav - lub luag haujlwm trailer (load peev 20 tonnes) mus rau ib qho trailer (load peev 15 tonnes), thiab tus nqi thauj mus los tau txo los ntawm CNY 1,200 ib ntu rau CNY 800 ib ntu; cov khoom siv hoisting tau hloov los ntawm 500-tuj crane mus rau 300-tuj crane, thiab tus nqi hoisting raug txo los ntawm CNY 8,000 ib ntu rau CNY 5,000 ib ntu. Tag nrho cov tsheb thauj mus los + tus nqi hoisting rau ib lub thawv girder tau txais kev cawmdim los ntawm CNY 3,400, offsetting qhov nce ntawm cov khoom siv, uas ua rau ib tug net txuag ntawm CNY 2,930 ib seem.

• Nqe Ntawm S690Q Steel Phaj

EN10025-6 S690Q, DIN ESTE690V High yield zog tus qauv
Teb Chaws Asmeskas $900.0-1100.0/Ton(FOB Nqe)

siab zog qib S690Q1 steel phaj rau spare qhov chaw
US $820.0/ Tons

ca steel quenched thiab tempered ntawm siab zog steel 1.8988 S690Q
US $500-1200/ Metric Ton

siab zog qis alloy steel phaj S690Q
US $475-690/ Metric Ton

S690Q S690QL S690Q High Tensile Structural Steel Phaj
US $550-800/Ton(FOB Nqe)

Ntev -Lub Sijhawm Ua Haujlwm thiab Kev Kho Tus Nqi Zoo Zoo

Tus nqi tiv thaiv -corrosion:S690Q kub dov steel phajmuaj ntau dua nto flatness, thiab tuaj yeem raug ncaj qha rau kev txhaj tshuaj blasting derusting + anticorrosive txheej tom qab kub dov, nrog cov xim zaj duab xis adhesion Ntau dua lossis sib npaug ntawm 5MPa; thaumQ345B kub dov steel phajxav tau kev kho kom zoo ntxiv, nrog rau xim zaj duab xis adhesion txog 3.5MPa. Muab xam raws li 20- xyoo kev ua haujlwm thiab kev saib xyuas lub voj voog ntawm tus choj, tus naj npawb ntawm cov txheej txheem tiv thaiv corrosion rau S690Q scheme raug txo los ntawm 3 zaug rau 2 zaug, txuag txog CNY 12,000 tus nqi tiv thaiv corrosion rau ib lub thawv girder.

Tus nqi tu tus qauv:S690Q kub dov steel phajmuaj kev ua haujlwm qaug zog zoo heev (lub zog qaug zog Ntau dua lossis sib npaug ntawm 300MPa), thaum lub zog qaug zog ntawm Q345B yog txog 200MPa; ntsuas cov ntaub ntawv qhia tias lub neej qaug zog ntawm S690Q lub thawv girder tuaj yeem ncav cuag 2 lab lub voj voog, thaum Q345B tsuas yog 800,000 cycles. Tsis pub dhau 20 xyoo, lub tswv yim S690Q tsis xav tau kev txhim kho cov txheej txheem, thaum Q345B lub tswv yim xav tau kev txhawb zog ntawm xyoo 10th, nrog tus nqi ntxiv ntawm kwv yees li CNY 50,000 ib ntu.

Engineering Performance Assurance

S690Q kub dov steel phajadopts Thermo-Mechanical Control Process (TMCP), nrog rau cov nplej loj li zoo li qib 7-8, uas tsis tsuas yog muaj lub zog siab, tab sis kuj zoo plasticity (elongation Ntau dua los yog sib npaug li 15%) thiab toughness (kev cuam tshuam lub zog ntawm -20℃Ntau dua lossis sib npaug rau 47J). Nyob rau hauv tus choj load xeem, qhov siab tshaj plaws deflection ntawm S690Q lub thawv girder yog 12 hli, deb tshaj qhov tsim txwv ntawm 18 hli; thaum lub siab tshaj plaws deflection ntawm Q345B lub thawv girder yog 15mm, ze rau qhov txwv. Tsis tas li ntawd, lub weldability ntawmS690Q kub dov steel phajyog sib xws nrog submerged arc vuam txheej txheem feem ntau siv nyob rau hauv txuas hniav, thiab lub zog ntawm welded ob leeg tom qab vuam yog ntau dua los yog sib npaug rau 650MPa, tsis muaj qhov tsis xws luag xws li tawg thiab porosity.

EN 10025-2 S690Q Daim ntawv thiab daim hlau sib npaug

Hauv cov ntsiab lus, txawm tias tus nqi ib -tonne procurement ntawmS690Q kub dov steel phajyog siab dua, kev txuag hauv kev thauj mus los, hoisting, thiab kev khiav hauj lwm thiab kev tu cov nqi coj los ntawm kev txo qhov hnyav ua rau tus nqi txuag ntau dua CNY 60,000 rau ib lub thawv girder tshaj nws lub neej voj voog. Ntxiv mus, nws tuaj yeem txhim kho cov qauv kev nyab xeeb thiab kev pabcuam lub neej ntawm tus choj, ua rau nws yog ib qho kev xaiv zoo tshaj plaws rau kev tsim qauv ntev -span, lub teeb yuag.

Thov Ib Qhov Quote

Yog tias koj xav paub ntxiv txog GNEE cov khoom, koj tuaj yeem xa email raualloy@gneesteelgroup.com. Peb zoo siab tshaj los pab koj.

FAQ

Qhov txawv ntawm S690Q thiab S690QL yog dab tsi?

S690Q: Yam tsawg kawg nkaus toughness kuaj ntawm -20℃(30J nruab nrab). → Hom Kev Siv: Cranes nyob rau hauv huab cua sov, cov khoom siv hauv av. S690QL: Muaj ntawv pov thawj rau -40℃thiab qis dua (Ntau dua lossis sib npaug rau 40J cuam tshuam toughness). → Kev siv tseem ceeb: Arctic pipelines, offshore platforms, mining tsheb hauv Siberia.

Cov khoom siv qib S690QL yog dab tsi?

S690QL yog lub zog siab quenched thiab tempered steel qib uas ua raws li cov lus qhia steel EN 10025. Qhov kev xaiv S690QL yog hais txog qhov tsawg kawg nkaus yield zog ntawm 690 MPa.

S690 qib steel yog dab tsi?

S690 high yield & fine grain steel phaj yog lub zog siab, quenched thiab tempered zoo -grain structural steel. Cov qauv hlau S690 yog siv rau hauv cov qauv uas yuav tsum tiv taus cov khoom hnyav heev. Qib no yog tsim los rau cov qauv uas kev txuag qhov hnyav yog qhov tseem ceeb.

Dab tsi yog qhov sib npaug ntawm S690 steel?

Kwv yees qhov sib npaug
ASTM A514, EN 10149-2 Qib S700MC, AS / NZS 3579 Qib 700, AM 700, Bisalloy 80.

Tus nqi ntawm S690QL cov khoom yog dab tsi?

S690QL High Strength Steel Phaj, Thickness: 5mm txog 150mm ntawm ₹ 135/kg hauv Mumbai.

Lub hardness ntawm S690 QL steel yog dab tsi?

S690QL steel stockholders thiab lwm tus neeg. S690QL yog quenched thiab tempered siab zog steel nkag rau hauv tag nrho daim hlau los yog txiav daim nrog xa mus rau tag nrho cov UK. Nrog nws cov txiaj ntsig siab ntawm qhov tsawg kawg nkaus 690MPa nws muaj lub zog zoo dua li cov qauv carbon steel qib.

Dab tsi yog kev siv lub zog siab S690 steel hauv kev tsim kho?

Lub zog siab S690 steels muaj lub zog zoo heev -rau - tus kheej - qhov hnyav piv, thiab lawv muaj txiaj ntsig zoo los siv rau hauv cov qauv hnyav hnyav. Cov ntawv thov ib txwm muaj xws li pawg thiab kab hauv tsev thiab txhawb cov tswv cuab hauv cov choj.

Dab tsi yog qhov txawv ntawm S890QL thiab S690QL?

S690QL, S890QL, thiab S960QL yog tag nrho cov dej quenched thiab tempered steels uas ua raws li EN10025: 6: 2004 specification. Cov hlau uas muaj zog heev no muaj qhov tsawg kawg nkaus tawm lub zog ntawm 690 MPa, 890 MPa, thiab 960 Mpa feem, ua rau lawv zoo tagnrho rau kev siv hauv kev thauj mus los.

Qhov txawv ntawm S700MC thiab S690ql yog dab tsi?

S700MC Steel yog ib qho ntawm cov qauv steel phaj tsim tshwj xeeb tshaj yog rau cov ntawv thov uas yuav tsum tau muaj zog yield zog. Lawv yog siv rau ntau daim ntawv thov load bearing. Lub S690ql yog cov hlau tsis tshua muaj hlau uas muaj zog thiab tuaj nrog kev sib txuas zoo.

Lub zog ntawm s690 steel yog dab tsi?

690 MPa ua.

Tawm lub zog ntawm 690 MPa. Siv nyob rau hauv cov qauv bearing hnyav hnyav, xws li txuas hniav, offshore drilling rigs thiab cov tsev, nrog rau cov khoom siv hnyav thiab cranes.
