09CuPCrNi-A Container Steel Atmospheric Corrosion Resistant Steel

09CuPCrNi-A Container Steel: Kev Lag Luam Tus Qauv rau Shipping & Intermodal Thawv

Yog tias koj tab tom tsim cov thawv ntim khoom, reefers, lossis ISO tso tsheb hlau luam,09CuPCrNi-Ib cua sov steelyog koj cov ntaub ntawv tseem ceeb tshaj plaws. Lub npe hu ua "Backbone ntawm Kev Lag Luam Thoob Ntiaj Teb," cov hlau no muab qhov sib npaug zoo tshaj plaws ntawm cov qauv siv zog thiab kev ua dej hiav txwv corrosion.

Raws li tus thawj coj ntawm 09CuPCrNi-A, peb nkag siab cov kev xav tau nruj ntawm kev lag luam ntim khoom. Nov yog yuav ua li cas peb hais txog 5 qhov kev txhawj xeeb tseem ceeb ntawm cov neeg siv khoom ntim khoom:

1. Maritime Corrosion: Nws puas tuaj yeem tiv taus 25+ xyoo ntawm hiav txwv?

Kev txhawj xeeb ntawm tus neeg yuav khoom:Cov ntim khoom ntsib cov tshuaj ntsev tas li, cov av noo siab, thiab raug UV heev.

• Peb qhov kev daws teeb meem:

09CuPCrNi-A yog engineered nrog lub siabCopper -Phosphorus (Cu-P)kev sib koom ua ke. Tsis zoo li cov hlau zoo tib yam, nws tsim cov tuab "spinel- qauv" oxide txheej (Patina).

• Qhov tshwm sim:Txawm hais tias cov xim sab nrauv raug khawb thaum tuav crane, cov hlautus kheej- kholos ntawm kev ua kom ruaj khov xeb thaiv, tiv thaiv kev sib sib zog nqus cov txheej txheem lwj. Nws lifespan yog5-8 lub sijhawmntev tshaj li tus qauv Q235 steel hauv saline ib puag ncig.

2. Siab -Speed ​​Cold forming: Nws puas yuav tawg thaum corrugation?

Kev txhawj xeeb ntawm tus neeg yuav khoom:Thawv sab vaj huam sib luag yuav tsum tau txias txias -bending los tsim "corrugated" (wavy) zoo li. Tsawg- cov hlau zoo yuav tawg ntawm qhov khoov.

Superior Elongation rau nyias -Gauge Forming (27.5% ntawm 1.0mm)

Rau ultra-nyias txias- dov 09CuPCrNi-A steel nrog lub thickness ntawm 1.0 hli, nws elongation tus nqi ntawm 27.5% deb tshaj li cov qauv kev lag luam. Qhov no txhais tau tias nws tswj tau qhov tshwj xeeb ductility thaum lub sij hawm siab - ceev corrugation ntawm lub thawv corrugated panels los yog complex 90℃/ 180℃dabtsi yog khoov, zoo tiv thaiv kev tsim ntawm microcracks.

Kev Ntsuas Kev Ntsuas: 1.0mm Txias -Rolled 09CuPCrNi-A Weathering Steel

Vim li cas peb cov Masteel batches yog qhov kev xaiv tseem ceeb rau Thawv & Precision Manufacturing?

Mill Test Certificate (MTC) saum toj no, muab los ntawmBaowu Masteel, qhia txog qhov tshwj xeeb ntawm peb cov 1.0mm txias-rolled steel strips. Rau nyias- ntsuas huab cua hlau, cov ntaub ntawv pov thawj no sawv cev rau "Gold Standard" hauv kev lag luam.

1. Txias Txias Superior -Kev Ua Tau Zoo (27.5% Elongation)

• Cov ntaub ntawv:Qhov tseeb Elongation (EL) ntawm27.5%ntawm 1.0mm thickness.

• Qhov zoo:Nyob rau hauv cov txheej txheem txias - dov, kev tuav cov ductility siab dhau los ua nyuaj dua vim tias daim ntawv nyias nyias. Txawm hais tias tus qauv yuav tsum muaj feem ntau Ntau dua lossis sib npaug li 22-24%, peb27.5%Cov txiaj ntsig tau lees paub ua kom cov hlau tuaj yeem ua haujlwm hnyavsiab -ceev corrugationthiab complex90℃/ 180℃dabtsi yog khoovtsis muaj kev pheej hmoo ntawm micro- tawg ntawm cov npoo. Qhov no ua rau kom qis qis qis hauv koj cov kab ntau lawm.

2. High Yield Strength rau lub thawv teeb yuag

• Cov ntaub ntawv:Yield Strength (YS) ntawm384 MPa ua.

• Qhov zoo:Txawm hais tias nws ultra-nyias 1.0mm profile, 09CuPCrNi-A muab lub zog tawm los ntau dua li cov qauv me me (Q235). Qhov no tso cai rau cov engineers ua tiav"Lub teeb yuag"-txo lub thawv ntim qhov hnyav kom nce lub peev xwm thauj khoom- yam tsis muaj kev cuam tshuam cov qauv kev nyab xeeb lossis cua- thauj khoom tsis kam.

3. Hwm Nto Zoo (FB Qib & Dull Finish)

Cov ntaub ntawv:Nto Zoo QibFB; Nto tiavD (Dub).

Qhov zoo:

• FB Qib:Ua kom muaj qib siab -zoo li saum npoo, tsis muaj qhov tsis xws luag uas tuaj yeem cuam tshuam cov qauv tsim lossis kev zoo nkauj.
• D (Dull) Ua tiav:Qhov tshwj xeeb micro- textured nto no yog cov "tus qauv" rau kev tsim khoom ntim. Nws muabsuperior xim adhesion, xyuas kom meej tias primers thiab anti-corrosive coatings " tuav" cov hlau zoo kawg nkaus. Qhov no tiv thaiv cov xim tev thiab nyob rau hauv - zaj duab xis corrosion thaum lub sij hawm ntev - thauj mus los hauv hiav txwv nyob rau hauv ib puag ncig ntsev.

4. Optimized Chemistry rau Rapid Patina Tsim

Cov ntaub ntawv:Phosphorus (P) ntawm0.092%thiab Sulfur (S) ntawm0.005%.

Qhov zoo:

• Cov ntsiab lus siab P & Cu:Guarantees sai sai ntawm cov tuab, tiv thaiv oxide txheej (Patina), txawm nyob rau nyias 1.0mm los xij.

• Ultra{0}}Low Sulfur:Thaum nkaus xwb0.005%, qhov kev pheej hmoo ntawm kub tawg thaum lub vuam yog zoo tshem tawm, kom ntseeg tau tias cov pob qij txha ntawm lub thawv tseem xau- pov thawj thiab ruaj khov nyob rau hauv kev ntxhov siab heev.

🛡️ Full Traceability & Quality Assurance

Qhov no MTC nqa cov ntaub ntawv zoo ntawmBaowu Masteel (Maanshan Hlau & Hlau), lub ntiaj teb ua steel conglomerate.

Thaum tshav kub kub naj npawb: 64416386

Coil Number: A24A025482

Txhua tuj ntawm 09CuPCrNi-Ib qho peb xa tuaj yeem rov qab mus rau qhov qub smelting kub. Qhov no ua kom lub zog zoo ib yam thiab tshuaj lom neeg ruaj khov rau koj qhov project tag nrho, txawm tias koj tab tom tsim 100 lossis 10,000 ntim.

Koj puas xav tau -precision txias-rolled weathering steel rau koj qhov project tom ntej? Hu rau peb pab neeg ua haujlwm rau ntau qhov kev tsocai thiab kuaj xyuas MTC cov qauv.

3. Weldability: Peb puas tuaj yeem tswj tau cov khoom lag luam siab?

Kev txhawj xeeb ntawm tus neeg yuav khoom:Cov thawv ntim khoom yog loj-welded. Cov hlau uas tsis zoo chemistry ua rau nkig welds lossis "kub tawg," ua rau xau.

Peb qhov kev daws teeb meem:
Peb nruj me ntsis tswj covCarbon sib npaug (Ceq). Nrog Carbon (C) txwv kom tsawg dua lossis sib npaug li 0.12% thiab Sulfur (S) tsawg li 0.006%, peb cov hlau muajzoo heev weldability.

Qhov txiaj ntsig:Nws yog sib xws nrog siab -ceev CO2 shielded vuam thiab submerged arc vuam. Cov pob qij txha tseem tawv txawm tias nyob hauv Arctic kub (-40℃cuam tshuam lub zog ntawm 168J), kom ntseeg tau tias lub thawv nyob twj ywm tawm - pov thawj thaum caij tsheb thauj mus los.

4. Lub zog-rau-Qhov hnyav piv: Peb puas tuaj yeem txo cov thawv ntim hnyav?

Kev txhawj xeeb ntawm tus neeg yuav khoom:Lub thawv sib dua txhais tau tias muaj peev xwm thauj khoom ntau dua (payload).

Peb qhov kev daws teeb meem:
Nrog ibYield zog ntawm ntau dua los yog sib npaug rau 345-400 MPa, 09CuPCrNi-A tso cai rau cov kws tsim khoom siv cov ntawv nyias nyias (xws li 1.6mm lossis 2.0mm) rau sab vaj huam sib luag yam tsis muaj kev nyab xeeb ntawm cov qauv.

Qhov txiaj ntsig:Qhov "lub teeb yuag" no txo ​​cov roj noj rau cov neeg nqa khoom thiab nce tag nrho Cov Nyiaj Rov Qab Los ntawm Kev Lag Luam (ROI) rau tus tswv lub thawv.

5. Paint Adhesion: Cov xim puas yuav tev tawm tom qab ib qho voyage?

Kev txhawj xeeb ntawm tus neeg yuav khoom:Weathering steel tej zaum yuav nyuaj rau cov xim rau "ko" yog tias qhov chaw tsis raug.

Peb qhov kev daws teeb meem:
Peb muab 09CuPCrNi-A hauvKub-Rolled Pickled & Oiled (HRPO)los yogTua- tawgraws li kev thov.

Qhov txiaj ntsig:Cov tshuaj muaj pes tsawg leeg ntawm 09CuPCrNi-A tiaginhibits "hauv- zaj duab xis" corrosion. Yog tias cov xim puas lawm, cov xeb yuav tsis "txaus" kab rov tav nyob rau hauv cov xim txheej, tiv thaiv loj - nplai tev thiab khaws cov nqi kho mob tsawg kawg nkaus.

09CuPCrNi-A Container Steel Specifications

Vim li cas thiaj Tau Koj Lub Thawv Hlau Los Ntawm Peb?

• Verified Mill Keeb Kwm:100% Maanshan Hlau & Hlau (Masteel) cov khoom lag luam.
• Daim ntawv pov thawj puv:Txhua qhov khoom xa tuaj suav nrog MTC ua rawsTB/T 1979thiabGB/T 4171.
• Npaj rau Export:Peb muab seaworthy ntim (steel strapping + waterproof ntawv) los xyuas kom meej koj coils / daim hlau tuaj txog nyob rau hauv pristine mob.

Txhim kho koj lub thawv ntim khoom nrog lub ntiaj teb kev ntseeg siab tshaj plaws huab cua steel. Tiv tauj peb rau ib qho kev tsocai ntau hnub no!

Peb muaj kev pabcuam zoo tom qab- muag. Yog tias koj muaj lus nug txog 09CuPCrNi-A atmospheric corrosion resistant steel, koj tuaj yeem tiv tauj peb thiab peb yuav teb koj li ntawm ob teev.

Dab tsi yog 09CuPCrNi-Ib qib steel phaj sib npaug?

thawj qhov sib npaug thoob ntiaj teb rau GB/T 4171 09CuPCrNi-A yog:

TS EN 10025-5: S355J0WP (Corten A sib npaug)

ASTM A588 / A588M: Qib A

JIS G 3114: SMA570W
